#workflow

Square Affair - with the X-Pro2!

Originally wanted to title this post “It’s Hip to Be Square”, like the refrain in the 1986 song “Hip to Be Square” by the American rock group Huey Lewis and the News … but it wouldna been appropriate. Any of youse know why? In that song the singer’s saying he’s starting to conform to the establishment coz he can’t stand the stress of being a rebel no more: i.e. it’s Hip (= cool, fashionable) to be Square (= conformist, following the rules). In photography most images have a rectangular aspect ratio (3:2 or 4:3). Using a square image frame (1:1) is therefore relatively rare, so you actually gotta be a bit of a rebel & break outta the rules if you wanna “go square” 😉!

Lantern and its shadow, seen with X-H1 and XF 90mm F/2 @F/8, 1/210 sec, ISO 400

Since 2010 Instagram has enjoyed a great success as online image sharing platform - until August 2015 only square images were allowed, driving somewhat of a renaissance of the square format: As Instagram is mainly viewed on smartphones, using a square image format means you aren’t required to turn your phone sideways for landscape images, allowing for a more ”smooth” user experience…

But the square format was there long before Instagram came along: Around 1930 first professional larger square format cameras appeared (Rolleiflex, Voigtländer and Hasselblad to name a few), using a reflex mirror to project the image onto a matte glass plate which could be viewed from above. This image was upright but laterally reversed. So if the camera would’ve had a rectangular image format it would have needed to be turned onto its side for portrait images, which would then have resulted in an upside-down viewfinder image! To prevent this inconvenience the manufacturers of the time stuck with a square image format

Interestingly enough there does not really seem to be much older history of the square format, eg. dating back to the times where images were still painted (at least I couldn’t find anything …)

Anyway, with the advent of the digital age came a greater flexibility regarding image aspect ratios, allowing the photographer to choose already in camera or afterwards in post production from a plethora of image formats from 16:9 to 1:1

You can apply the square format during image capture (obviously this works only for JPEG´s - the RAW image always uses the full native format of the camera) or in post production. I usually prefer to decide that when developing the image in Capture One Pro - some images only lend themselves to the square format at a second (or third) glance!

Original image, with 1:1 square crop

For example, take a look at my first image of this post. I only saw the potential for a tighter square image format when preparing it for uploading to my blog (inspiring me to create this post “Square Affair” on the square image format 😉) On the picture with the blue square frame you can see how it looked originally: Cropping it to a square shape has left out unimportant parts of the image, focusing on the main elements, lines and shadows. I imagine this has just always been a square image just waiting to be discovered! What do you think?

So, what’s behind all this “square” talk? Basically the main quality of this frame is that it creates a natural sense of balance, stability & symmetry. None of the sides is favored, preventing any distraction from the image content. The square composition allows you to eliminate negative space & superfluous elements in your image - excessive space in an image invites a viewer’s eye to wander away from the subject & makes your subject look a bit lost. The square has an inherent classic & beautiful design, which if carefully applied will make your images stand out from the crowd! Because the square lacks any horizontal or vertical bias the viewer’s eye tends to be guided in a circular motion, often converging towards the centre of the image

Wall with shadow of another lantern, captured on X-H1 with XF 90mm F/2 @F/8, 1/600 sec, ISO 400

In the above image I could leave out the right side of the rectangular frame because the shadow of the lamp already tells the story - don’t need to have the lamp itself inside the frame no more 😉)

Original image with 1:1 square crop

See here the original framing on the image with the blue square frame. In this case I was not really happy with my initial picture - should’ve gone a bit closer to leave out the white strip on the lower edge of the frame … I learnt from this that you gotta “work” the image more - instead of just one or two frames per subject it would be better to try out different perspectives, distances & framings, giving you more material to work with and increase the chance of getting that perfect image!

As you can see in the image with the lamp below the square format also circumvents the otherwise ubiquitous “rule of the thirds”: The square frame gives you more freedom to place the central element of interest - usually a slightly off-centre position of the main subject is enough to create sufficient tension in the composition!

Lantern surrounded by canvas roof, discovered with X-H1 and XF 16mm F/1.4 @F/5.6, 1/5 sec, ISO 400

Here you can see another example: The original image is nice, but includes too much empty (= “negative”) space on the left and right sides. Cropping it to a square focuses on the essential part of the image: The steps with their diagonal lines and railings. As you can see, the content of the left & right borders does not really add anything to the image & I think you will agree that the square image is much more powerful: The square frame gives the image a much more dynamic & interesting look!

Original image with 1:1 square crop

In this case I have to admit that I was planning to put this image into a square frame all along. By the way, using the full rectangular native image format and later extracting a square crop during post processing allows you to place your square off centre to create a different perspective. This can help if you are photographing a reflecting house façade or window directly from the front and want to prevent seeing your reflection in the image: You place the square all the way to one side of the rectangle, resulting in your reflection not being visible anymore!

Steps in a square frame, seen with my X-Pro2 with XF35mm F/2 @F/8, 1/180 sec, ISO 200

Now before y’all gettin’ too excited here, there’s just one caveat: When shooting square you gotta be aware (WOW, that rhymes ;-) that shooting in the square format reduces your lens’s effective angle of view. The angle of view of a lens determines how much of the image you can cover and is calculated according following formula: 𝜶 = 2arctan(d/2𝑓), where 𝜶 (alpha) is the lens’s diagonal angle of view in degrees, d represents the length of the image’s diagonal in mm (28.23mm for the uncropped Fuji APS-C sensor) and 𝑓 is the focal length of your lens in mm. For those of youse not so much into math here’s the thing: Cropping your native 3:2 aspect ratio image to a square 1:1 aspect ratio generates a field of view (FOV) which makes your lens look like the next longer lens in your system. For example Fuji’s XF 18mm / 28mm Full Frame equivalent FOV behaves like the XF 23mm / 35mm Full Frame equivalent FOV lens, the XF 23mm / 35mm Full Frame equivalent FOV like the XF 35mm / 53mm Full Frame equivalent FOV, and so on - basically you can multiply your focal length by a factor of appox. 1.2 when going square! See the below image, taken with the XF 16mm, it looks more like an image taken with the 18mm:

Dinner out with best friends, image taken on X-H1 with XF 16mm F/1.4 @F/2, 1/40 sec, ISO 2500, +0.7 EV

So I hope I’ve managed to inspire youse to experiment a bit with the beautiful, serene and classic square format, and hope you’ll “dare to be square” (again a rhyme 😉). Please share your experiences in the comments section below or leave me a note on my “about” page. Look forward to the discussion!

PS: The best thing about going square is: It don’t cost you nothin’, jeez - this accessory is completely FREE 😊!

Peace with y’all and wish a very nice weekend

Cheers,

Hendrik

If you like you can support me by sending me a small donation via PayPal.me/hendriximages ! Helps me run this site & keeps the information coming, many thanks in advance!

There IS a Life Without Image Stabilization | Fuji XF16-55mm F2.8 WR NoOIS!

Afraid of the shakes? No problem, use image stablization, or “OIS” (Optical Image Stabilization) as Fuji calls it. Some hate it. Most love it, can’t be without it like as if they’re addicted. Was like that with me too. Thought I couldn’t live without it. Until I took a decision which forced me to survive without the anti-wobble technology. Please read on to find out what happened (especially if you don’t care ;-)

I know you don’t care ... this one didn't need no image stabilization, X100F 23mm @f8, 1/120sec

As long as you live in daylight it don't really matter. Any lens does just fine. But when the sun drops below the horizon & light becomes scarce your "any lens" is gonna need either a flash, a tripod, or an image stabilization crutch. That'd work assuming you want to photograph a static subject. But as soon as something in your image moves (and you want to render it reasonably sharp) there's only ONE option: Aperture! The larger the better. Get the largest aperture you can find. Image stabilization ain't gonna help and yes, flash would still be an option but that's not really viable if you want to capture the charm of available light. The image below was taken hand held. Would’ve needed image stabilization. Didn’t have it:

Too cold to sit outside. Night time bar scene, XF 16-55mm at 16mm, @f/2.8, 1/20sec, ISO1250

Coz I’d traded my XF 18-135mm f/3.5-5.6 (with OIS) to get an XF 16-55mm f/2.8 (without OIS). This Lens' missing OIS has caused some on the net to fondly call it "The Brick" (like as in a worthless paper-weight). Now why would I go and trade my perfectly good OIS zoom for such an OIS-less "Brick"? It wasn't easy but in the end the following factors tipped the scales for me in favor of the "Brick": I've learnt I need 5 things for my architecture / landscape / people photography:

  1. Max possible aperture to freeze subject movement (image stabilization don't help here!)
  2. With at least a 16mm (24mm FF equiv.) on the wide side for architecture & group photos
  3. Reaching at least up to portrait focal length (85mm FF equiv.) on the long side
  4. High quality zoom lens - don’t fancy changing lenses (I got amathophobia - fear of dust ;-)
  5. Portability: Reasonably compact camera/lens combo, no tripod or gear bags to lug around

So, Fuji´s XF 16-55mm f/2.8 WR fits above requirements like a glove (while my XF 18-135mm missed out on the first two). I use the XF 16-55mm predominantly for reportage and portraiture, where my subjects are usually moving. In this scenario image stabilization don't really help me. Even it would've been technically possible to also include OIS, the caveat of further increasing size and weight (and not to forget the price) of the lens would have not been worth it (for the previously described use case). I guess Fuji followed a similar logic when they decided to opt out of OIS on the "Brick". The lens is reasonably compact and remains portable. It's also perceived as being less intrusive by your subjects. Try putting the XT-2 / XF16-55mm combo next to a comparable CaNikon full frame DSLR with 24-70mm f/2.8 zoom attached. You'll see what I mean, pushing a DSLR lookin' more like a WMD into someone's face probably´ll scare the living daylights outta them, turning a lively bar scene into something like the image below ;-)

All quiet bar after closing time, captured with XF 16-55mm at 16mm, @f/2.8, 1/18sec, ISO3200

A word on aperture: The advantage of the smaller (vs. full frame) APS-C sensor is that you get more depth of field at the same aperture due to the shorter focal length compared to the full frame equivalent focal length. For example a 50mm "normal" lens on full frame has a field of view comparable to a 35mm on APS-C. Using f/2.8 on both delivers more depth of field in the APS-C image as there the lens needs to be of shorter focal length to achieve the same angle of view. Consequently the disadvantage of APS-C is that you´d need a larger aperture vs. full frame to get a more shallow depth of field and similar subject - background separation. For example a 85mm full frame portrait lens will render the background in a pleasing blur at f/2. To get a similar effect with an APS-C equivalent focal length of 55mm you'd need at least f/1.4 ... My XF 18-135mm had a max. aperture of around f/4.5 at 55mm and I needed to stop down to f5.6 to get optimal sharpness in portraits, which means my max. aperture in full frame terms would be only around f/4. Apart from the lower brightness which forced me to use higher ISO´s I could never really achieve a pleasing background separation like in this image with the XF 16-55mm:

My pretty wife, wearing my glasses, with XF 16-55mm, at 55mm @f/4, 1/450sec, ISO400

Just the way I like it, the eye closer to the camera sharp and sharpness nicely dissolving towards the rear into a completely blurred background!

Now, coming back to my initial statement: There IS a life without image stabilization, please see proof in the image below. It was shot hand-held at 1/8sec with my XF 16-55mm f/2.8 zoom at its long end (55mm APS-C / 85mm full frame equiv.), without the "benefit" of image stabilization. Ok, so OIS would've helped here, coz there are no moving subjects in the image. But as the majority of images I make with this zoom have moving subjects, the added weight, size and cost of OIS would not be worth it in my opinion!

Night-time street scene, with XF 16-55mm at 55mm, hand-held @f/2.8, 1/8sec, ISO3200

I hope this post was interesting for y'all & able to give you some advice in case you're on the fence to acquire the XF 16-55mm "Brick" - believe me, you'll find it's more of a "Nugget" than a "Brick". A gold "Nugget" - an amazing lens which you'll use for more than 90% of your images. No more changing lenses, risking missed image opportunities and/or getting dust inside your camera! While weight & size remain reasonable, the X-T2 or X-Pro2 combo fitting snugly in a small pouch

Best regards,

Hendrik

I hope this post was helpful / interesting for you - If you like you can support me by sending me a small donation via PayPal.me/hendriximages ! Helps me run this site & keeps the information coming, many thanks in advance!

How to Win Time With Fuji!

Time. The “fourth dimension“. We can’t control it. We just live in time, but can’t travel in it like we can in 3 dimensional space. Moments passed can never be revisited. They only linger as memories in our mind or saved as images taken. That’s why time’s so precious, don’t waste it! Fortunately we can choose what to do with our time. It’s a very personal choice. If you’d love to maximize your free time photographing the world around you with your Fuji, I may have something interesting for you to minimize time spent image editing. Please read on to find how to win more time with your (Fuji ;-) camera:

Wooden Bridge, seen with XF 35 / f2 R WR on Fuji X-Pro2, JPG developed in LR CC mobile

To be faster & more efficient on the image processing bit, editing your JPEG’s with Lightroom CC on a mobile device’s the way to go: You can work while traveling or waiting at airports & it syncs your image processing seamlessly with Lightroom CC Classic on your MAC/PC. Means you can continue where you left off when you’re back at your desktop! You can then happily save up RAW files of your favorite images for those long winter evenings (when the next blizzard hits ;-) to eke out that last bit of highlight detail (which eluded you on your JPEG’s) via Fine Art editing & printing using Capture One Pro on your Mac/PC. See below a schematic representation of my workflow:

I usually download my JPEG images (just ACROS Black & Whites for me ;-) to my iPad Pro via WiFi using the ShutterSnitch App. IMO better than Fuji’s Camera Remote App, but a bit pricey. For that I can automatically update images´ metadata with my copyright during import & rate / sort out the ones I want to process later before exporting them to iOŚ’s photo library. From there I “add“ them to an album called ’JPEG’. I do like this coz of iOŚ’s dorky image filing system, where all images on the iPad are dumped into the camera roll: taken images, processed images, screenshots, the whole smash - all in one big mess you ain’t ever gonna find anything in. So by “adding“ your images to a separate album (or albums) you can find them easily afterwards for importing into Lightroom CC mobile. See below some screen shots of my workflow once in Lightroom CC mobile (please click on the thumbnails to see more details):

processing in LR CC mobile

when done, select ’open in‘

& size for web / social media

in Phonto App, to

add your copyright

in your preferred format

WiFi download? Boy, you can easily go for lunch while that’s going on (Fuji JPEG´s typically got around 16Mb ;-) OR, in case you’re in a hurry, transfer them to iPad via Apple’s SD card to Lightning Adaptor, but then there’s no automatic IPTC copyright update & no way to preview images before saving them in the camera roll ...

Ok, ‘nuff said, for sure y’all interested about what settings I use for my JPEG’s (coz choosing the JPEG route means many settings can’t be modified after the fact. I always shoot RAW/F (RAW + fine JPEG’s) to always have backups of the original files, either to experiment later with differing RAW to JPEG conversions in camera, or for more precise RAW post processing using Capture One Pro. In camera I use following settings:

  • ACROS-R film simulation (of course ;-)
  • -1 Highlight tone
  • +3 Shadow tone
  • Grain effect off (ACROS film simulation already has its own grain effect!)
  • -3 Noise reduction
  • 0 Sharpness (more sharpening in camera creates visible artifacts)

This delivers pin sharp, contrasty black & white JPEG’s with punchy shadows & smoothly gradated highlights. And they got ACROS film simulations’s amazing tone dependent film-like grain effect! Only minor adjustments in post processing are needed, if at all. For me adjusting the images’ tone curve is the most important means to create image depth and giving them a 3 dimensional look. Please also check out Patrick la Roque’s amazing article on this topic!

Apart from the s-shaped tone curve the second most important thing for me is to accentuate the sharpness - I keep the sharpening amount low but up the detail level, see below:

Fall in the Park, captured by XF 35 / f2 R WR on Fuji X-Pro2, JPG developed in LR CC mobile

So, all in all no big deal. With this simple & fast mobile workflow needing only a couple moments attention for each image before uploading to my blog and/or social media I can complete post processing in no time, during commuting or while enjoying a latte in a cafe. See another example here, shot shortly after sunrise:

Bayreuth on Sunday Morning, XF 35 / f2 R WR on Fuji X-Pro2, JPG developed in LR CC mobile

This way I can maximize time spent on enjoying the world around me & taking images! Please let me know your thoughts, or ask me via my contact page if have any further questions / need any advice, thanks for your interest & for looking by!

I hope this post was helpful / interesting for you - If you like you can support me by sending me a small donation via PayPal.me/hendriximages ! Helps me run this site & keeps the information coming, many thanks in advance!

Best regards,

Hendrik

Capture with Style!

Been some time since I posted ... Was kinda busy movin´ house & couldn't find my camera ;-) Now I´m back with Style! Capture (-ing) with Style, using Capture One Pro 10 with a modified Style (never liked the "canned" stuff, always like to do my own thing!). Please read on to find out more!

Into the Sun, with XF 35/2 WR on X-Pro2, Capture One 10 with modified BW-15 Style

In Capture One Styles are sets of presets driving several adjustments simultaneously, while presets adjust only a single parameter, eg. "grain". Means you can dramatically speed up your post processing workflow by applying such Styles during image import. By selecting a Style suiting your needs you can automatically adjust eg. gradation curve, sharpening, noise reduction, etc. of your images when importing your images into Capture One and you´re already 90% done without lifting a finger!

Bridge in the Park, with XF 35/2 on X-Pro2, Capture One 10 with modified BW-15 Style

As already mentioned here my favorite Capture One Style is the BW-15 (grain) black & white Style, which IMO comes closest to Fuji´s amazing ACROS JPEG film simulation. But the grain´s too much salt in my soup and the default sharpening settings seem a bit too aggressive. So I was trawling (not trolling, mind you ;-) the net for optimal Capture One settings in combinmation with Fuji´s 24mp X-Trans III RAW files & stumbled across Thomas Fitzgerald´s "X-Trans-Files-in-Capture-One-Guide". A great read, costing only 4€ and well worth it in my opinion!

Red Chair on Stone Patio, XF 16-55/2.8 WR @16mm, X-T2, CO 10 with modified BW-15 Style

Using Thomas´ settings for 24mp RAF files in Capture One 10 as a starting point I modified Capture One´s BW-15 (grain) Style by reducing grain level to 60 and optimizing sharpening and noise reduction settings slightly (of course you can also use your own favorite settings). The trick is to select an image, apply the style, adjust the various settings to your satisfaction and save it all as a new Style (take care to deselect those items which are image dependent):

Deselect presets which are image dependent!

This ensures the same film simulation, gradation (tonality curve) and grain are saved in your new Style but image specific parameters, like exposure, contrast, etc. are not affected!

Apply saved Style & auto adjust on import!

Then select your new Style and "auto adjust" in the import menu. This makes Capture One apply your Style and auto adjusts exposure parameters automatically during import, resulting in 90% ready images, which only need minor final tweaking (if at all)

View from Villa Sermolli over Buggiano in Tuscany, Italy, X-T2 with XF 16-55/2.8 WR @23mm

Summarizing, Fuji JPEG´s are good but RAW files just have that extra flexibility: If you want to get the best outta your images you gotta go RAW, allowing you eg. to change color sensitivity (like applying color filters during post processing) and offering that extra bit of highlight headroom. Looking forward to your comments, questions, and critique, thanks so much for looking by,

Best regards,

Hendrik

I hope this post was helpful / interesting for you - If you like you can support me by sending me a small donation via PayPal.me/hendriximages ! Helps me run this site & keeps the information coming, many thanks in advance!

Picktorial - A New Kid on the Block for Fuji Fans!

Hi! Stumbled over this: Picktorial v3 post processing software (Mac only - special introductory offer!). Many thanks to Fujirumors (good place to get the latest Fuji news) and Thomas Fitzgerald (where I always go for expert image processing advice) for pointing me to it! The main reason I´m now starting to use it for all my post processing is coz for the first time there is ONE SIMPLE, intuitive platform for image management AND processing, compatible with Fuji JPEG and (compressed / uncompressed) RAW images, please read on how so!

Candles in Church, Fuji X-T2 and XF 23mm / f2, ACROS JPEG processed in Picktorial

As mentioned before here I mainly use ACROS JPEG´s & rarely do RAW anymore. So, a couple weeks ago I was in an awesome Russian orthodox church with my lovely wife & fancied capturing the rich gradations and tonality of this scene. Then I would´ve developed the ACROS JPEG with Lightroom CC (LR) and resorted to Capture One (CO) in case I´d want to try any fancy RAW processing ... But I really don't like hulking for hours behind a computer. Nope. And, using different bits of processing software means I need to have all kinds of directories on my Mac to save intermediate versions of my images (I´m kinda paranoid about losing my work ...). On top of this both LR and CO use catalogues, so I need to manage and back up those too ... I tell ya, I could've become an IT expert (who maybe gets to take a photo now and then ;-). No sir, not good. Not good at all!

Picktorial has an intuitive, fluid & simple user interface (look & feel very similar to Apple´s legendary Aperture, which was unfortunately discontinued). Overall it´s very minimalistic: No jumping around between library and develop panes as in LR. It works directly in your image capture folder and stores your image edits in the image file (for JPEG, TIF, DNG) or in a XMP sidecar file (for RAW) w/o changing the original image. By this non-destructive workflow you can backtrack your work anytime (even taking out single steps) and save your image as often as you want without any image degradation. If you want to transfer your images just be sure to copy the whole directory (images incl. the XMP files), then you can just pick up from where you left off!

Russian Orthodox Mural, Fuji X-T2 and XF 23mm / f2, ACROS JPEG processed in Picktorial

Another great Picktorial feature is the luminosity masks (yes, photoshop has those too, but it´s much easier to use with Picktorial), please check out this great instruction video from Eric Marcs at findingmiddleearth.com (I´m still a learner on how to do that properly ;-)

The only additional feature I could wish for is to have a mobile version for my iPad which can sync with the desktop version (like Lightroom mobile), that would be awesome!

Picktorial offers an easy, fluid, and seamless experience and is much faster than Lightroom, I love the simplicity and intuitivity of the user interface!

Last but not least I compared the results with my until now preferred applications:

RAW file processed in Picktorial

RAW file processed in Iridient Developer

JPEG file processed in Picktorial

RAW file processed in Capture One Pro

RAW file processed in Photo Ninja

JPEG file processed in Lightroom CC

Summarizing the results I can recommend Picktorial as an easy & fast processing tool for those who want to minimise post processing effort & get best possible results w/o a lot of effort

Many thanks for visiting & please leave me a message in case anything is unclear or is you´ve any questions, best regards

Hendrik

I hope this post was helpful / interesting for you - If you like you can support me by sending me a small donation via PayPal.me/hendriximages ! Helps me run this site & keeps the information coming, many thanks in advance!

Fuji Lightroom Mobile Workflow Revisited

As promised in my previous post I´d like to share with y´all my mobile workflow, using Fuji cameras, an iPad and Lightroom Mobile! If you wanna get freed from your desktop, speed up your processing / image sharing on web and if you´re interested in becoming a more efficient photographer, please read on!

The Messenger, seen in Sicily with Fuji X100F, 23 mm / f2 @ f5.6, 1/320", ACROS-Y, 400 ISO

I mentioned in my previous blog post that Fuji´s ACROS film simulation with its tonality and ISO dependent grain effect delivers JPEG´s with a film-like look that can not be achieved via traditional RAW processing. These JPEG´s are so good that they liberates you forever from having to fuss around with RAW files & RAW converters (spending hours behind a computer, trying to get image quality comparable to Fuji´s amazing JPEG´s). This in turn enables a more mobile approach to photography, so get liberated & embrace a JPEG based mobile workflow!

Required equipment:

  • Camera with Wifi capability (check out Fuji´s website but it can be any brand ... ;-)
  • Mobile device with sufficient processing power & free space for saving images
  • WiFi connectivity App to transfer images from your camera to your mobile device
  • Lightroom Mobile (and Adobe Creative Cloud subscription if you want to sync to desktop)

To get your images downloaded onto your mobile device of choice (in my case an iPad Pro 9.7"), there are 2 options (when using Fuji cameras, as I do ;-)

  1. Fujifilm´s "Camera Remote App" (download free from iTunes or Google Play)
  2. 2nd Nature´s "ShutterSnitch" Wireless Transfer App (download for US$ 18.99 from iTunes - no Android version yet). Expensive but IMO much better as it includes all kinds of goodies: image organisation in collections, image preview using zoom, saving to various media, metadata update (I don't use this as it re-saves my JPEG´s potentially reducing image quality slightly), etc.

While Fuji´s Camera Remote App downloads your images directly to the iPad´s camera roll, ShutterSnitch requires them to be exported (I prefer this coz it keeps my images organized outside Apple´s somewhat difficult to understand & confusing filing system). See below the procedure for ShutterSnitch, the end result in both cases is that the images you want to process end up on the iPad´s camera roll

How to get your images onto Camera Roll using ShutterSnitch ...

Next step is to import the images you´d like to process into Lightroom Mobile. You can stop here but if you also have Adobe´s Creative Cloud subscription (around 12-13 US$ per month) you get a seamless synchronisation between your mobile device and desktop (images processed on mobile device are updated on your desktop device when you connect to your home network & vice-versa). Cool!

Importing your images into Lightroom Mobile ...

Importing your images into Lightroom Mobile ...

In Lightroom Mobile you will find the familiar develop modules from the desktop version (Basic, Tone Curve, etc.) and you can adjust the settings as required:

Post Processing in Lightroom Mobile!

As mentioned before these adjustments are then synchronized with your Lightroom desktop version as soon as you connect to your home network (provided you have Adobe´s Creative Cloud installed)

Summing up. this mobile workflow allows you to already perform the main rough image post processing steps while on the move (mainly curves and some exposure / contrast improvement) In most cases the processing options offered by Lightroom Mobile are sufficient, so no further desktop processing is needed! :-)

I hope you enjoyed this post and you can use it to enhance your own photographic experience, please leave me a note in the comments section if anything´s unclear or if you have any further questions,

Many thanks & best regards, wish y´all a great start into the new week & lots of fun, best regards

Hendrik

I hope this post was helpful / interesting for you - If you like you can support me by sending me a small donation via PayPal.me/hendriximages ! Helps me run this site & keeps the information coming, many thanks in advance!

Three Intuitive Features that will make your Fuji X-T2 "Disappear" !

At the end it´s the images that matter. The camera´s just a tool, a means to an end, a vehicle to manifest and visualize your perceptions, impressions and emotions of the wonderful world around you! The less that camera gets in your way, the more intuitive / less intrusive its operation, the better your images will be! Fuji´s X-T2 has 3 distinct, unique features that help it to come closer to this ideal than any other camera I´ve experienced so far! You want to discover how to set up your X-T2 to make it magically "disappear" and enable you to fully focus on your images? Please read on, and as a bonus I show y´all a cool trick below not yet seen elsewhere on the web … ;-)

Shadows on the street, Fuji X-T2, with XF 18-135 mm WR at 18 mm - f5.6 - 1/950 sec - ISO 400

Above image with contrasty shadows painted on the pavement is easily overseen when using an optical viewfinder ...

The Fuji X-T2 has 3 distinct, unique features enabling an intuitive, non intrusive work-flow:
1. World´s best EVF (Electronic View Finder)
2. Only camera with always visible exposure triangle settings (physical dials iso menus)
3. No interruption of viewing when changing settings (how to configure the user interface)

These play a key role in the 2 criteria responsible for getting those special images (or should I say helping those special images find you):

  • Being able to accurately pre-visualize your image, so you can be sure it tells the story you experienced or imagined when seeing the scene
  • Being able to effortlessly and intuitively adjust the settings to suit your perception w/o needing to take the camera from your eye

Below these important 3 features are discussed in more detail:

1. World´s best EVF (Electronic View Finder):

The main advantage of an EVF over any optical viewfinder (as found in DSLR´s or rangefinder type cameras) is a realistic WYSIWYG (what-you-see-is-what-you-get) view: Means you can pre-view the image exactly as it will be saved, i.e. incl. film simulation, color, white balance, exposure, contrast, etc. settings applied. In the film era you only saw the result after getting back the developed film (meaning a delay until being able to review your images and then often having no way to redo anything in case something didn’t turn out as expected). This pre-visualization feature of an EVF dramatically shortens the learning loop (scene impression > viewfinder preview > image capture > image development > final image review > optimization), thereby exponentially increasing the hit-rate of your photographic process!

10 steps to heaven ... X-Pro2 with XF 35 mm / f1.4 at f5.6 - 1/340 sec - ISO 400 (-2 EV)

So what´s so special about the X-T2´s EVF? While sporting a best in class magnification of 0,77X and a state-of-the-art 2,36M-dot resolution (like X-T1), the X-T2´s EVF has a significantly higher refresh rate (100 fps in boost mode) and half the view finder black-out time (5 ms), compared to the X-T1. Compared to the X-Pro2 it has an increased viewing angle (38° vs 29°) and a longer eye point distance (23 mm vs. 16 mm) which significantly improve view-ability and ease of viewing (especially for eyeglass wearers!)

It´s the combination of the above characteristics that enables a truly immersive and enjoyable viewing experience and animates you to use the EVF in the first place! In fact the overall improvement is now such that for the first time I prefer the X-T2´s EVF over all other options (OVF or LCD): For me the X-Pro2´s EVF now appears too small & slow, with too narrow viewing angle and the X-T1´s EVF could not really convince me at the time to go full EVF (especially in lower ambient lighting conditions), so I sold it last year …

Once actually using the EVF, turning "preview PIC effect" to ON in the menu (MENU > Wrench > Screen set-up > Preview Pic. Effect > ON) is the KEY feature allowing you to pre-visualize the image exactly as it will be taken by the camera (e.g. as a black & white image focussing on contrast, form and light / shadow distribution rather than colors)

The window wall, Fuji X-T2, with XF 18-135 mm WR at 62 mm - f8 - 1/550 sec - ISO 400

2. Only camera with always visible exposure triangle settings:

Exposure triangle means aperture, shutter speed & ISO settings - the 3 key elements determining image exposure and appearance. together with the exposure compensation dial you have 4 separate, dedicated manual dials on which you can immediately and always see/check the settings before lifting the camera to your eye, meaning you can preset the camera before taking the shot! As far as I know the Fuji X-T2 is the only one among high-end digital cameras having this traditional “photographer´s” user interface layout

On top of this Fuji´s approach to switching between program modes is much more intuitive & self-explanatory:

  • Program mode: Aperture & Shutter speed dial on "A" > all elements are set automatically, depending on lighting conditions, ISO and exposure compensation setting
  • Aperture priority mode: Aperture set on required f-stop (eg. to ensure required depth-of-field), shutter speed dial on "A" > shutter speed is automatically adjusted depending on lighting conditions, ISO and exposure compensation setting
  • Shutter priority mode: Shutter set on required shutter speed (eg. to freeze action or to synchronize with flash), aperture on "A" > aperture is automatically adjusted depending on lighting conditions, ISO and exposure compensation setting
  • Manual mode: Aperture and shutter speed set to required values (eg. for special lighting conditions / effects) > aperture and shutter speed are fixed. But with Auto-ISO you can still get a certain level of automatic exposure!

Holy windows, Fuji X-T2, with XF 35 mm / f1.4 at f5.6 - 1/480 sec - ISO 400 (-1 EV)

3. No interruption of viewing when changing settings (how to configure the user interface):

Your camera becomes an obstacle to your creative pre-visualization process and inspiration if changing settings forces you to take your eye from the viewfinder. Instead of concentrating on your subject you then need to divert your attention to fiddling with dials and menus. A camera which can be personally configured to allow changing settings without needing to remove your eye from the viewfinder will go a long way to missing fewer opportunities and allowing you to focus on what really matters: the image. In other words the camera kinda “disappears” from disturbing your work flow, see below how to do this!

I´m a “left eye dominant” shooter. When using my X-Pro2 this means my nose is squashed onto the LCD, resulting in frequently needed cleaning to remove smudges. I also gotta squint around the viewfinder to see the whole image (shorter viewfinder eye point and narrower viewing angle than X-T2). On the X-T2 my nose ends up clear to the right of the LCD but I can´t properly access the AF-L button as my nose and right thumb are competing for the limited real estate around the thumb-grip on the right hand side of the camera. Bummer, coz I love using the “back button focus” technique (means AF is initiated via a separate button rather than by half pressing the shutter release - gives me better control on what I want to focus on!

Fortunately the X-T2 offers me a work-around: By allocating “AF-ON” function to the front Fn2 function button I ca use a "front button focus" technique (long press “DISP BACK” button > Fn Button Setting menu appears > scroll down to Fn2 and right-click using 4-way controller > select “AF-ON” > confirm with “MENU OK”)

I don't (like to) use the "AF-L" button - IMO it´s misplaced coz the thumb rest partly blocks using it. Luckily this button can also be re-assigned on the X-T2, so I allocated the "Flash Function Setting" to it (use that sometimes for fill flash) and the "Shutter Type" selection to the somewhat difficult to reach Fn1 button. Pressing it cycles thru the shutter types MS > M+E > ES (which I mostly use to keep the camera quiet)

There´s more, you won´t find this nowhere else on the web: A special "Hendrix" X-T2 Fn-button configuration which allows me to fully focus on my image in the viewfinder, see the Fn-Button Settings in the image on the right:

The trick is to place the functions most used during viewing on the Fn3 and Fn6 buttons to get a fluid settings adjustment workflow in combination with the 4-way controller!

xt2 af mode.jpg

The Fn3 and Fn6 buttons are the top and bottom buttons on the 4-way controller. So, when activating the functions allocated to them you can fluidly change their function setting by continuing to press the same bottom or top button on the 4-way controller without needing to change finger position or taking your eye from the viewfinder ... COOL!

No confirmation via the "MENU OK" button is needed, half pressing the shutter release is enough. This "trick" only works for the top and bottom 4-way controller buttons. For functions allocated to the left and right buttons you need to change your finger position to the top or bottom 4-way controller button to scroll thru the function settings. This does cause some disruption of the viewing experience and may distract your attention from your image subject. Try it & you´ll immediately experience how much more fluid changing settings can be!

Holy windows, Fuji X-T2, with XF 35 mm / f1.4 at f5.6 - 1/480 sec - ISO 400

A final tip: If you want relatively fast access to 2 more secondary functions (over the 8 already assigned to Fn-buttons), you can allocate them to the top/left slot on "Q-Menu" and the 1st slot on "My Menu". These slots are faster to access as they are automatically highlighted first when selecting the Q- or My Menu. This saves some valuable time due to not needing to scroll around

I´ve allocated the top/left slot on the "Q-Menu" to the "Select Custom Setting" function (which I use to select different film simulation / setting configurations) and the 1st. slot of the "My Menu" to the "AF-C Custom Settings" function (which I use to switch between AF-C configurations depending on subject movement type)

For me it was important to get the configuration of the camera right from the start, and NOT CHANGE it afterwards, so that I could develop a consistent muscle memory fitting that configuration

With this review I´d like to encourage y´all to experiment to find the best settings for your kind of photography and work-flow, my preferred set-up is not necessarily applicable for everyone!

Many thanks for looking by & look forward to hearing your comments & experiences,

Best regards

Hendrik

I hope you enjoyed reading this post - If you like you can support me by sending me a small donation via PayPal.me/hendriximages ! Helps me run this site & keeps the information coming, many thanks in advance !

Fuji ACROS: Amazing JPEG´s with Film-Like Grain !

Since Fuji appeared on the scene we have been spoilt by intuitive cameras delivering wonderful images & amazing JPEG´s - Hey, some photographers didn't´t even wanna touch RAW´s ! And now that the new 24 MP X-Trans CMOS III sensor is here (Fuji X-Pro2, X-T2 and the new X100F) we get as bonus the ACROS film simulation mode for smoothly gradated black and white JPEG´s with deep blacks and a beautiful film-like grain texture. Interested how to get the best out of ACROS ? Please read on !

Waiting at the Airport, seen with Fuji X-Pro2 and XF 16 mm f1.4 WR, SOOC ACROS JPEG

Since going digital I´d always missed that "organic" film kinda look I got from my beloved Kodak Tri-X negs (man, I loved that film ...). Now, finally I can get it in digital - just compare below crop of a RAW file, developed in Capture One Pro 10 (left image) to crop from the original SOOC JPEG, which sports a subtle but distinct grain effect:

RAW developed in Capture One Pro 10

SOOC ACROS JPEG

This grain is amazingly "organic", way better than the more "sterile" digital grain which is applied in post as a generic image overlay eg. with 3rd party software ! ACROS has some kind of magic algorithm built in which selectively applies analogue grain, depending on ISO level and tone - you get "photographic" looking images with wonderful smooth gradations and a subtle "film-like" grain, right off the bat:

50 Shades of Lighter Grey ;-) captured by Fuji X-Pro2 & XF 35 mm f2 WR, SOOC ACROS JPEG

To achieve such JPEG images SOOC and still get sufficient "punch" in the shadows I apply following settings in my X-Pro2´s Q-menu (saved as preset):

  • ACROS-R film simulation
  • GRAIN effect OFF (ACROS has its own built-in ISO dependent analogue grain effect)
  • -3 NR (noise reduction)
  • DR auto (auto dynamic range)
  • -1 H-TONE (highlights contrast)
  • +3 S-TONE (shadows contrast for sufficient "punch")
  • +1 SHARP (sharpening)

I´ve discovered that the sweet spot (detail rendering vs. micro-contrast vs. grain) for ACROS simulation is around 2000 ISO. To compensate the JPEG´s reduced highlights & shadows recovery latitude (vs. doing RAW development) I set the highlights tone to -1 (increased highlight tonal range) and my dynamic range to "Auto" (automatically adjusts dynamic range to the subject contrast), see example image below:

Casting Shadows Ahead, with Fuji X-Pro2 and XF 35 mm f2 WR, SOOC ACROS JPEG

I´ve really fallen for this ACROS film simulation, and you can't get it any other way except by shooting JPEG´s ! So I set my camera to record RAW´s & Large/Fine JPEG´s. This allows me to speed up my workflow by primarily using JPEG´s and having the RAW as a back-up in case tricky post processing is needed (only in approx. 10% of the cases). Another benefit is that the image review on the camera´s LCD uses this high quality JPEG rather than the embedded low quality one when shooting RAW only

Hope y´all enjoyed this post & there was something interesting in it for you ? Thanks for looking by and of course you´re most welcome to leave me constructive critique and/or questions in the comments section below or on my "about" page !

Best regards & have fun shooting !

Hendrik

I hope you enjoyed reading this post - If you like you can support me by sending me a small donation via PayPal.me/hendriximages ! Helps me run this site & keeps the information coming, many thanks in advance !

Want Best Image Quality From Your Fuji ? Here´s How !

After my first try-out of Phase One´s new Capture One Pro v10 (here) I thought those of youse in constant search of getting the very best image quality might be interested in a re-comparison of latest available RAW development solutions ! For this I took a challenging high contrast image shot after dusk - quite scary how much achievable image quality still varies among contemporary RAW converters. Curious ? Please read on !

Great result: XF 18-135mm @18mm f/5.6 1/8" on X-Pro2, developed in Capture One Pro 10

Small side remark: I´m repeatedly amazed about what I can do with Fuji´s XF 18-135mm OIS (Optical Image Stabilization): Apart from replacing a full bag of lenses I´m getting sharp results down to 1/8 sec at any focal length (sometimes even 1/4 sec !) - Hello ... that´s 4-5 stops autonomy vs. non OIS lenses ! Means I could take the above image of a museum venue after dusk at ISO 3200, f5.6 and 1/8 sec hand held !

Ok, so before looking at the various RAW converters I´d first like to share the SOOC JPEG taken with Acros-R film profile - a bit too dark for my taste:

Original SOOC JPEG, using ACROS-R film profile - too dark IMO !

I compared following RAW converters (in order of preference):

Disclaimer: I am not affiliated with any of the above software providers, nor a "fan-boy" of any one of them - I just choose the best solution for my type of images and workflow. However I excluded some RAW developers (Raw Therapee, Silkypix, ACDSee, Aperture, ...) from this comparison as these either were not available to me, or not compatible with Mac OS Sierra, or having an IMO too complex user interface (eg. Silkypix). So, in case you don´t agree to my conclusions you´re most welcome to leave me a comment and/or suggestions below !

Basically I aimed for maximum highlight recovery and dynamic range, covering all zones from pure black to white with balanced gradations of grey in between. I further tried to prevent over sharpening (to which Fuji X-Trans files do not agree too well). Below you can see 200% crops of results achieved with each RAW converter (arranged in order of my personal preference):

My Conclusions:

  1. Overall Capture One Pro 10 delivers IMO the most balanced result, with good contrast and sharpness in the background billboard text and not too aggressive rendering of the grass and the hedge. Capture One now automatically corrects distortion (often prevalent on zooms) by straightening & cropping. However, left at 100% this correction effectively reduces the FF equ. widest angle of view of the XF 18-135 from 27mm to 28.5mm. So I reduce the auto-correction to around 60% allowing me to retain around 28mm FF equ. max. field of view while still getting reasonably straight lines
  2. Photo Ninja brings out more contrast in the text but IMO renders the tree, grass and hedge too aggressively. The image also seems to be overlaid by a visible grain structure. Unfortunately Photo Ninja doesn't´t offer lens correction based on embedded EXIF data and delivers somewhat strange colours (for those into colour imaging)
  3. Lightroom CC delivers reasonable results, albeit with subdued sharpness in the text (with optimal settings for Fuji X-Trans) and a hint of detail smearing artefacts in the foliage
  4. Iridient  (my previous favourite, before trying the newest version of Capture One) disappointed me on this image: I couldn't get sufficient contrast in the text and finest details in that text do not seem to be resolved well enough (lines in the letters break up). Also here IMO too aggressive rendering of the grass & foliage
  5. Affinity Photo delivers a similar balanced result to Capture One but clearly lacks contrast, sharpness and detail rendering in the fine details of the background text
  6. The SOOC JPEG is IMO the least attractive of these (apart from being too dark). This confirms that JPEG´s, while being good enough for sharing images on social media / web are insufficient for big fine-art enlargements - see how the fine details in the text are lost ...

Another aspect to consider is that from my point of view only 2 solutions of the above offer a complete all-in-one image management / RAW development solution: Capture One Pro and Lightroom CC. The others are usually applied as external RAW converters integrated into a Lightroom workflow, requiring exporting and re-importing of images & more complicated handling

Even Capture One is currently my preferred image management solution it has one big deficiency: It is the only software of the above NOT able to handle compressed Fuji RAW´s. This means each RAW file blocks approx. 50mB of your disk space vs. the approx. 25mB per compressed RAW !

Ok, this will be my last post of this year. I sincerely hope you enjoyed visiting my blog during the past year & will continue to follow me thru 2017 ! As always please leave me any comments and/or questions you may have in the comments area, many thanks for your continued support & for your interest / contributions !

Wishing y´all a wonderful, successful, fun new year 2017 & the best of luck for all your (photographic ;-) endeavours,

Yours,

Hendrik


I hope you enjoyed reading this post - If you like you can support me by sending me a small donation via PayPal.me/hendriximages ! Helps me run this site & keeps the information coming, many thanks in advance !

Capture ONE Pro 10 for Fuji - A First Look !

When I jumped ship from CaNikon to Fuji a couple years ago I didn't find ANY integrated RAW converter / image management solution able to deliver the full potential outta Fuji´s unique X-Trans sensor. Only way out was to use a standalone external RAW converter (eg. Iridient) requiring a 2 step workflow. Then, earlier this year Adobe launched a major Lightroom CC upgrade delivering results very close to the till then Best-in-Class RAW converter Iridient (see my comparison here). Finally on December ONE Phase ONE launched Capture ONE Pro, version ONE-O. Hey, with so many ONE´s popping up I thought I´d take a look and see, please read on for my initial impressions !

Street in the winter sun, captured by Fuji XF 23 mm f/2 WR on X-Pro 2, developed in CO Pro 10

I decided to try out the newest version 10 of Capture One Pro after being intrigued by Thomas Fitzgerald´s excellent blog post describing latest improvements & features, please go here to discover them ! For me the above image has a wonderful glow to it and it took me only a couple minutes to get there - impressive how fast & easy I could get a really good result ! Furthermore Capture One Pro allows me to change any parameter at any time in its logical and clear dashboard (see left side of the screen grab shown below):

Capture One Pro 10 User Interface with logically grouped intuitive setting panels

What I liked most was the fluid interaction between Exposure, Levels, Curve, High Dynamic Range and Clarity settings. In contrast Lightroom IMO has a more linear (chronological) workflow which feels less intuitive and kinda "old fashioned" ...

Concluding, the PRO´s of Capture One Pro 10:

  • Great results. At least at a first glance I couldn't detect any disadvantages vs. my previous favorite Iridient in eg. highlight/shadow recovery, color rendering, detail rendering, sharpening, noise, etc (but I´ll come back here with a more detailed comparison soon)
  • Lens optimization finally working (incl. purple de-fringing !) - this was missing in previous versions of Capture One Pro
  • Fluid, logical and intuitive user interface allowing changing of all parameters in any order
  • NO more external standalone RAW converter needed ! Capture One Pro combines RAW conversion and image management. Strictly speaking this is no advantage over Lightroom

And the CON´s:

  • Capture One Pro 10 can´t read Fuji´s compressed RAW´s (yet). Now this one is really a bummer for me coz Fuji´s uncompressed RAW´s eat up memory at twice the rate compared to the compressed RAW´s (50 vs. 25 mB a pop !). C´mon, Phase One, give us the compressed RAW reading capability, you can do it !
  • Pricey - nearly 300 US$ ain´t a bargin (even though you get a lot for it). Ok I have a CO Pro 8 license so it´ll cost me 105 US$ to upgrade. Still a lot ... but at least it ain´t a subscription rip-off like CC (if you can live without Photoshop CC that is)

Here another "glowing" Capture One Pro image:

Contre Jour in the park, seen with Fuji XF 23 mm f/2 WR on Fuji X-Pro2, developed in CO Pro 10

If you have any questions or would like any advice, please leave me a message in the comments section or on my contact page ! Many thanks for your kind support, interest, liking & sharing ! Herewith wishing y´all a lot of fun trying out Capture One Pro 10 ! Enjoy your December holiday season, all the very best & good luck !

Yours, Hendrik

I hope you enjoyed reading this post - If you like you can support me by sending me a small donation via PayPal.me/hendriximages ! Helps me run this site & keeps the information coming, many thanks in advance !

How to Get Best Image Quality Out of Fuji X-Trans III RAW´s

Hey I got something for those of youse who REALLY wanna get the very best possible image quality out of Fuji´s new X-Trans III image sensor (as currently used on Fuji´s X-Pro 2 and X-T2 mirrorless APS-C cameras). Yeah I know ... Said some posts ago that Lightroom´s all you´ll need ... Basically that still holds true but it all depends on what you expect from your photography, please read on to discover how:

Portrait of my lovely wife: Fuji X-Pro 2 with 35 mm f2 WR @f2.8 1/125 sec

Portraits seem to present quite a challenge regarding image quality (apart from the obvious challenge to capture the right facial expression reflecting persona & character of your model ;-) ! Working on a portrait series I discovered that different RAW developers produced subtle variations in the results. So I thought I´d share them here, starting off as baseline with Fuji´s very good SOOC JPEG rendering. This already delivers an overall pleasing result, however finest details are lost during in-camera conversion:

SOOC JPEG using Fuji X-Pro 2´s X-Trans III 24 mp sensor

Then I tried RAW conversion using Affinity Photo, a relatively new kid on the block (many thanks to The Lightweight Photographer for pointing me to it !). With this one I do get a very nice contrast, which I initially liked a lot (for me nearly the most pleasing off the bat). But on closer scrutiny I discovered it dissolves finer details even more than the JPEG and also produces some unwanted artefacts (see the line between the cornea and the lower eyelid):

RAW conversion using Affinity Photo

This is not the case with Adobe´s latest version of Lightroom CC. Better fine details than the JPEG´s and a fully integrated workflow to boot (no external RAW converter, so no additional exporting / importing needed). However ACR does seem to slightly exaggerate high contrast fine detail - the eyelashes seem to look a bit thicker / heavier than perceived (I learnt a lot from Thomas Fitzgerald´s excellent X-Trans guides & used one of his sharpening presets, they´re really good !). To further optimize this I may need to experiment a bit more in detail with the sharpening settings:

RAW conversion using Adobe Camera RAW in Lightroom CC

Last but not least the most balanced high quality result came out of Iridient Developer: Extremely fine details are retained and beautifully rendered (using default "Iridient Reveal" sharpening). No artefacts, no exaggeration, IMO the very best result I could achieve (with a reasonable effort - I really want to minimize the time spent in front of my Mac, of course ;-)

RAW conversion using Iridient Developer

Concluding I have to say that Fuji shooters have a lot of choices nowadays: Need a fast result w/o hassle ? You can use the SOOC JPEG´s without any problem, they´re amazing ! Want to go RAW for a really good result with an integrated workflow ? Lightroom CC ain´t gonna disappoint you ! But if you want the very best image quality & don't shy away from some extra workflow integration ? Use Lightroom CC for image management and Iridient for RAW conversion (it can be easily integrated into your workflow - excellent "how to" advice available here)

Hope y´all liked today´s post & could find some guidance & information for your own work ? If you´ve any questions, comments or ideas - please leave me a note in the comments section or on my "Contact" page ! Many thanks for reading, for your continued interest & support, and hope to see you here again soon !

Good luck & best regards,

Hendrik

I hope you enjoyed reading this post - If you like you can support me by sending me a small donation via PayPal.me/hendriximages ! Helps me run this site & keeps the information coming, many thanks in advance !

Adobe´s got the best RAW converter for Fuji X-Trans now, or what ? Part 1

Recently I got this pop-up on my MAC informing on new Creative Cloud App updates, so I downloaded ´em & was looking at some high contrast images after import using Lightroom´s ACR (Adobe Camera RAW). Here FYI the JPEG SOOC, with totally jacked highlights & shadows:

Dogging the Fountain - Fuji X-Pro2, WR 35mm/f2, JPEG SOOC: Jacked highlights & shadows !

But when opening the RAW´s with ACR - what the ... ??? ;-) Hey, could it be that Adobe´s now finally gotten their Fuji X-Trans rendering act together ? Intrigued by this performance I decided to (again ... yawn ;-) compare Adobe´s Camera RAW (included in Lightroom & Photoshop CC) with the best external RAW converters out there (Iridient & Photo Ninja) - ya just gotta keep on your toes here ;-) please read on if interested !

I´ve been using Photo Mechanic for culling / key-wording & Lightroom for (mobile) image management / processing since way back, so obviously a built in RAW converter would have major advantages for my workflow compared to an external one (no more needing to export & copy back in, nor splitting image processing over 2 bits of software, etc.)

I´m posting this in 2 instalments: 1. Highlights & Shadows Performance (this post), and 2. Detail & Sharpening (coming up soon !)

Let´s start with Highlights & Shadows Performance. Although aesthetically the SOOC JPEG quite faithfully rendered what I´d originally visualised at time of capture the highlights & shadows are like totally blown out. So I was interested how much detail I could pull back into the image during post processing:

To do this I basically first maxed out the highlights recovery and then pushed the shadows by slightly increasing exposure until just before the highlights started blowing out again (thereby keeping an eye on not losing too much contrast). See below the comparison & results !

1. Adobe Camera RAW in Photoshop CC:

This one I liked the most:

Highlight & Shadows compression using Photoshop CC´s built in ACR RAW converter

Dunno why, but i seemed to get a slightly better rendering outta Photoshop´s built in version of ACR than LR´s (maybe the PS ACR interface is better, or I was too dumb or lazy to get 100% the same result with Lightroom´s built in ACR ...). Here a 100% crop view showing vastly improved shadows & highlights areas vs. the JPEG:

100% Crop of Photoshop´s ACR rendering

2. Adobe Canera RAW in Lightroom CC:

Nearly as good (yeah, right - both platforms use the same Adobe Camera RAW built in RAW converter):

Highlight & Shadows compression using Lightroom CC´s built in ACR RAW converter

Here a 100% crop view showing the improved shadows & highlights areas, with slightly less contrast in the shadows whereas highlights seem to have a bit more detail ...

100% Crop of Lightroom´s ACR rendering

3. Iridient Developer:

Iridient is amazing in its ability to bring out detail with a unique & careful sharpening of Fuji X-Pro2´s files, but I was quite shocked to see that its highlight & shadows detail recovery seems to be limited:

Highlight & Shadows compression using Iridient´s external RAW converter

Compared to ACR the highlight head room is quite limited, meaning I have less "foot" room available for pushing the shadows, before the highlights blow (compare the crack between the tiles on bottom right with the ACR versions):

100% Crop of Iridient´s rendering

4. Photo Ninja:

This one I liked the least - highlight head room seems a bit better than Iridient, but didn't matter what I did, i just couldn't manage to bring out more shadow detail (it always kinda remained a dark soup). Also Photo Ninja does not react on EXIF lens correction parameters, you get the total image (see the additional details at the image borders), but the image is still distorted:

Highlight & Shadows compression using Photo Ninja´s external RAW converter

And here the details - highlights OK´ish but the black dog just remains a black silhouette:

100% Crop of Photo Ninja´s rendering

Sorry, did´t have no more access to Capture One & never used Raw Therapee so those two are not covered here ...

Interim Conclusion: Adobe´s ACR wins the dynamic range battle !
(please also check out part 2 soon for details & sharpness comparison and for the final conclusion)

From a highlights & shadows recovery point of view the benefit of not needing to use external RAW converters seems to be an achievable target, Adobe´s ACR is doing an excellent job here ! OK I´d not push it that far for a fine art print to preserve the visual impression of the original situation, but good to know there is room for manoeuvring !

I hope this was an interesting read for all you Fuji fans out there - please leave me a comment in case you´ve any questions and/or suggestions ! Many thanks for looking by & wish y´all good light !

Best regards

Hendrik

I hope you enjoyed reading this post - If you like you can support me by sending me a small donation via PayPal.me/hendriximages ! Helps me run this site & keeps the information coming, many thanks in advance !

WOW ! Combining X-Pro2´s X-Trans III and Iridient

Finally I dunnit - after reading lotsa reviews and years of frustration with windows OS (jeezus, I needed to become more of an IT expert than focussing on improving my photography ...) I jumped ship to Mac. This now opened the door to using Iridient RAW developer (which unfortunately don´t exist for Win users ...). Well to put it mildly, I was completely blown away with the results !!!

Spring coming to Hofgarten in Bayreuth

Gone the issues with smearing foliage or fine details artefacts i´d experienced with various windows based RAW converters off Fuji X-Trans sensors ! Using Iridient´s R-L deconvolution setting with radius 0.5 and 30 iterations I get a clear but subtle sharpening effect w/o visible artefacts, demonstrating the amazing details Fuji´s new 24 MP X-Trans III sensor is capable of rendering. I still use Lightroom for my image management (yeah, some old habits die hard ;-) but using LR proprietary RAW converter just don´t cut it, see below:

Iridient RAW development - nice & crisp !

LR RAW development - still a bit mushy ...

To integrate Iridient RAW developer into Lightroom I set up:

  1. LR to use Iridient as external RAW editor: LR export menu > export to same folder as original, add to catalog & stack, TIFF, after export open in Iridient ...
  2. Iridient to open the original RAW image (not the TIFF copy !): Preferences > tick "Find & Load RAW for TIFF, JPEG, ... open events"

White fence in the last afternoon sun ...

When exporting an image from LR to Iridient (right click > export to Iridient) LR creates a "place-holder" TIFF from the RAW image but Iridient opens and develops the original RAW file related to it. When done in Iridient the developed RAW overwrites the TIFF "place-holder" in LR by using file > process image and overwrite option. Then back in LR just apply some finishing touches (B&W conversion, curves, exposure, contrast, highlight / shadow recovery, etc) and you´re done !

Candlelight dinner with my lovely wife (no flash !)

I hope y´all liked this post & could get some inspiration off it - my apologies to my readers & followers that I´ve neglected my blog for a several months: moving house & starting up new job and all ...

Please let me know if you got questions or need any support in how to set up the various bits of software so this works smoothly and/or which settings to apply for  best results (but on that one I´m still on a learning curve m´self, so please bear with me a little while ;-)

Many thanks for reading & look forward to hearing from you, appreciate if you´d leave your comments or constructive critique in the comments window below or drop me a mail !

Thanks in advance & warm regards

Hendrik

I hope you enjoyed reading this post - If you like you can support me by sending me a small donation via PayPal.me/hendriximages ! Helps me run this site & keeps the information coming, many thanks in advance !

Going "light" - Mobile Post Processing without PC!

So, that's it. Finally I dunnit - switched my online workflow fully to mobile, meaning: Using Fuji JPEG's, RAW developed in camera & post processed only on my iPad before uploading to my blog / social media! No more PC? Well, not quite - for those of you interested, please read on ...

Rainin' up?

I always capture RAW+JPEG(F)'s. This way I have the best possible sensor output (14 bit RAW) of my Fuji X100T for later making large prints (normally up to A1), using PhotoNinja RAW conversion & Lightroom on my PC. But believe you me, the workflow for getting fine art quality prints of that size off an APS/C format sensor takes a LOT of effort, is very time consuming and very expensive to boot!

On the other hand sharing images on the web luckily don't require such stunts ... The "light", On-the-Go workflow shared here - based on using the amazing 8-bit Fuji JPEG's has proven to be more than enough for web use IMO - please take a look for yourselves:

No guests? Deserted bar in Sardegna

I already previously shared "prototypes" of this mobile workflow on my blog, but needed to further refine some steps / choice of tools to make it more fluid & efficient, here the final 6-step workflow:

  1. Capture - Fuji X100T set to RAW+JPEG(F); B(R) film sim; sharpening +1; hi-light & shadow +1; NR -1; DR, WB, ISO on auto (ISO base 200, max 1600, min SS 1/80). Configured like this the X100T acts like a "monochrome" camera with preview & review of images in contrasty B&W!
  2. After the shoot, I check the images in camera & delete those which are unsharp / poorly exposed (washed out hi-lights) and/or have unsatisfactory content (this helps reduce the amount of "waste" on storage media & in my archive)
  3. In camera RAW conversion of "keepers" to flat "digital color negatives", with following settings: CC film sim; color +1; hi-light & shadow -1
  4. Download these "color negatives" to my iPad via WiFi, using Shuttersnitch App (which automatically updates IPTC metadata with copyright & usage rights, etc.)
  5. Process on iPad into final B&W images using Photogene4 App. I did previously use Pixelmator but found the processing options in Photogene4 to be more useful (eg. hi-light & shadow recovery) and the its user interface more fluid. Only disadvantage of Photogene4 is that the healing tool can only do spot healing (instead of Pixelmator allowing me to paint over areas, but that I don't need so much anyway)
  6. Finally I add my copyright text to the image, resize to 1500 pix web dimension, save to output folder and upload to my blog / social media - DONE!

Here another example - even in 8-hit the dynamic range of Fuji's JPEG's is impressive:

Two chairs four two?

Well, I hope this was helpful for some of you? Doing PP on iPad during traveling has seriously reduced the amount of time I needed to spend staring into a PC screen at home - Now I got much more time for taking photos (or for relaxing with a glass of fine Italian prosecco ;-)

Thanks for reading, please let me know what you think (comment below or send me email)!

Best regards,

Hendrik

I hope you enjoyed reading this post - If you like you can support me by sending me a small donation via PayPal.me/hendriximages ! Helps me run this site & keeps the information coming, many thanks in advance !
